WATERFLOW INDICATOR
The Vane Type Waterflow Indicator (Waterflow Detector) Is Used To Detect A Sustained Flow And Give a Signal On Wet Pipe Sprinkler Systems. It Includes Mechanical Time Delay Features To Reduce The Risk Of False Alarms.
Sensitivity:
Flow Rate 4-10 US GPM
Contact Rating:
8A at 125/250 VAC, 3A at 24VDC, 2.5A at 30VDC 18
Maximum Surge:
Feet Per Second (FPS)
Temperature:
0°C to 68°C
Working Pressure:
450 psi
Surface:
FBE Coating as AWWA C550
Certificate:
UL Listed / FM Approved
Standard:
ANSI / UL 346
